Ocular IQ Home Solar | 7kW | Socket
Welcome to the future of charging with the IQ Home, our cutting-edge charging solution is designed to meet the needs of modern electric vehicle owners, offering versatility, efficiency, and convenience at their doorstep.
The system comes with CT clamps to measure your solar production excess, which enables you to charge with green, free electricity from your solar panels, and protects your home from overloading. The IQ Homes has three different charging modes to suit your individual needs and solar production levels. Built to withstand the Australian elements, it comes with IP55 protection, ensuring reliable performance in any weather conditions. The unitās compact design makes it ideal for residential settings, allowing for easy installation and seamless integration into your home.
- 3 Charging Modes ā Fast, Solar Assist or Solar Only
- Charging Speed ā 7kW (40km of driving per hour of charge)
- OCPP Enabled
Safe ā Power BalancingĀ
The Ocular IQ Home Solar has energy balancing for energy restricted homes especially in the hot Australian summer. The Ocular IQ Home Solar senses energy limitations in your home and adjust your charging speed to avoid overloading your electrical supply.
Utilising CT clamps the Ocular IQ Home Solar senses a homeās available electricity. It can read the incoming feed to the building, take into account the building energy usage and calculate a final amount of power that is then distributed to the charger.
The IQ Home Solar reads the power feed every second and reduces the power output when other home appliances, such as a water heater, air condition systems are turned on. Once the water heater is turned off, the charger will automatically read the available power and increase the power output to the maximum available level. This gives you the maximum charging speed without tripping your homes power.
Technical Specifications:
| Power Output | : | 7.2kW (1-Phase) |
| EV Charging Connector | : | Type-2 Socket |
| Input and Output Voltage | : | 230V Ā± 20% |
| Input and Output Current | : | 32A max per phase |
| Recommended Circuit Breaker | : | 40A type A RCBO |
| Frequency (Hz) | : | 50/60Hz |
| CTs Included | : | 1 |
| CT Length of Signal Line | : | 20m (Extendable up to 100m with insulated twisted pair cable) |
| CT Primary Rated Current | : | 100A max current |
| CT Internal Diameter | : | 16mm (fits max cable size 50mm2 XLPE) |
| Display | : | LED indication lights |
| RFID Reader | : | ISO14443 Type A cards compatible |
| Charger Control Method | : | Mobile app, physical button, RFID, start on plug |
| Internal RCD | : | 30mA AC & 6mA DC Leakage |
| Electrical Protection | : | Over current, Short circuit, Over voltage, Under voltage, Ground fault, Lightning surge, Over temperature |
| OCPP | : | 1.6J and 2.0.1 (Firmware upgrade required) |
| Internet Connection | : | Ethernet, Wi-Fi, 4G |
| Additional Communication Type | : | Modbus (TCP/IP) |
| Energy Meter | : | Integrated Meter |
| Load Control | : | Compatible with Ocular Load Controller or OCPP smart profiles |
| Ambient Air Temperature for Operation | : | -30āĀ°C to +50Ā°Cā in operation |
| Ambient Air Temperature for Storage | : | -40Ā°Cā to +70Ā°Cā in storage |
| Working Humidity | : | 5% - 95% relative humidity, non-condensing |
| IP Performance | : | IP55, IK10 |
| Mounting | : | Wall Mount |
| Dimension (H x W x D, mm) | : | 398 * 285 * 226 mm |
| Net Weight | : | 1.5 kg |
| Certification | : | CE, IEC /EN 61851-1, IEC 61008-1-A1, IEC 62955-1-A1, IEC/EN 61851-21-2, IEC 62196-2, RCM |
| Warranty | : | 3 Years (Extended warranties available) |
